ABS Plastic Spool can be used for winding cables, ferrous wire and non-ferrous wire in the pay-off and take-up of wire drawing machine, stranding and bunching Machine etc.The ABS is a spool for ABS (acrylic-lyer-butadiene symbol) as the main raw material. It is characterized by: high surface brightness, strong material, strong anti-fall and anti-impact, and chemical corrosion. It is generally used as a wire winding with higher quality requirements.

product-750-750

Main Specifications

Model specifications	structure	-	Material	side panel		barrel diameter	total lengthL1	inner widthL2	apertured3	carrying hole	-	-
				diameterd1	thicknesss					radius	eccentricity	-
				diameterd1	thicknesss					-	e1	e2
PC-100	integration	turnover disk	PC	100	10	50	90	70	20	-	-	-
PC-125	integration	turnover disk	PC	125	10	65	120	100	20	-	-	-
PN300	combination	turnover disk	PS	300	15	140	L2 30	-	30	7	30	50
PN310	combination	turnover disk	ABS	310	12	130	215	185	25-40	8	46	46
PN355	integration	turnover disk	ABS	355	20	224	200	160	27.5	11.75	80	50
PN400	combination	turnover disk	ABS	400	16	200	300	250	40-56	10	60	74.5
PN400	combination	turnover disk	ABS	400	20	200	300	250	55-57	10	60	74.5
PN500	combination	turnover disk	ABS	500	20	250	300	250	56	12.5	70.5	98.5
PN500	combination	turnover disk	ABS	500	20	250	375	315	56	12.5	70.5	98.5
PN630	combination	turnover disk	ABS	630	25	250	475	400	56	10	90	106
PN630	combination	turnover disk	ABS	630	25	315	375	300	56	12.5	77.5	102.5
PN630	combination	turnover disk	ABS	630	25	315	475	400	56	12.5	77.5	102.5

Characteristic

1.Unitary body of perfect balance

2.It's injected by ABS, PS, and other alloy materials.

3.High strength, no kinking, durable, support recycle using

4.Minimum tolerance can reach to 0.05mm.

Application Field

Wire processing and manufacturing industry, wire and cable industry.
