1. Product Overview:
Wire Rod Drawing Machine is used for drawing Aluminum rod or Aluminum Alloy rod from 9.5 to 1.7-4.8mm wire, followed by dual spool take-up.The double-spool take-up device adopts a pneumatic system, which has fast response speed and stable operation, ensuring that the reel can be changed without stopping the wire, and has high productivity. Both sides can use for supporting long life.
2. Main Specifications:
|
Machine Type |
LHD450/13 |
|
Max.Die No |
13 |
|
Inlet wire dia |
9.5mm |
|
Outlet wire dia |
1.7-4.8mm -Al 2.3-4.5mm -Al-alloy |
|
Max.Speed |
25m/s |
|
Capstan dia |
450mm |
|
Main motor |
280kw (DC)-Al 315kw (DC)- Al-alloy |
|
Fix speed capstan motor |
75kw(DC) |
|
Take up motor |
22kw×2 |
3. Advantages of Wire Rod Drawing Machine :
1. The Wire Rod Drawing Machine adopts horizontal type designing and is easy to operate.
2. Capstans drive by motor with inverter through gear boxes, power saving.
3. Using fully immersing lubricant which can ensure the complete cooling and lubricant of wire and dies
4. Similar Product:
11 Dies Rod Breakdown Machine for Aluminum
5. Application Field:
Wire processing and manufacturing industry, wire and cable industry.
6. Machine Guarantee:
12 months from the date of loading, except for easy wearing parts and the seller will not guarantee the period due to buyer's misuse of the machine.
